Rattler TS25-384 Compact Short/Medium Range Thermal Imaging Rifle Scope
The AGM Rattler TS25-384 and the Rattler TS35-384 are the compact thermal imaging scopes developed for 24 hours operation under any weather and environmental conditions. Two objective lens options allow the customer to choose the perfect unit for your needs. The 25 mm lens is designed for short range shooting, while the 35 mm lens model will be great for medium range missions.
The thermal image riflescope has 384x288 thermal detector and 1024x768 OLED monitor, which provides clear image under harsh environment conditions like darkness, fog, smoke, dust, rain, snow, brush, camouflage, etc. The device can be used as a thermal riflescope or handheld monocular. The scope is mainly applied to scenarios such as patrolling and hunting, etc.
Powered with two CR123 batteries the AGM Rattler TS-384 gives up to 4.5 hours of continuous operation time. An optional external (5V) battery pack can be easily connected via a USB connector for a significant increase in operating time. Onboard Wi-Fi module for live video streaming and video/images recording via application are also available.
- 384 x 288 thermal resolution, high sensitivity detector
- Image processing technology: Adaptive AGC, DDE, 3D DNR
- 1024 x 768 resolution 0.39-inch OLED display
- 8x digital zoom
- Video recording and snapshot, built-in EMMC (16GB)
- Supports distance measurement
- Adjustable color palettes
- Wi-Fi data transmission
- Waterproof, shockproof
- Up to 4.5 hours continuous working
- External power supply capability
- Powered by two standard CR123 batteries
- Limited 5-year warranty
Package includes: Thermal Imaging Riflescope, Mount, USB Cable, Lens Cloth, Soft, User Manual
| Detector Type | 17µm Uncooled Microbolometer |
|---|---|
| Resolution | 384 x 288 px |
| Refresh Rate | 50 Hz |
| Lens System | 25 mm; F/1.0 |
| Optical Magnification | 1.5x |
| Field of View | 14.9º x 11.2º |
| Digital zoom | 1x, 2x, 4x, 8x, PIP |
| Observation Range | Max 965 yds |
| Eye Relief | 45 mm |
| Display | 0.39-inch, OLED, 1024x768 |
| Hotspot | Yes |
| Distance Measurement | Yes |
| Scene Mode | Jungle, Recognition |
| Standby Mode | Yes |
| Video Recording | Yes |
| Picture Snapshot | Yes |
| DPC | Yes |
| Uniformity Correction | Auto, Manual, External Correction |
| Storage | Built-in EMMC (16GB) |
| Battery Type | Two CR123A 3V lithium batteries |
| Battery Life (Operating) | Up to 4.5 hours |
| Power Supply | 5V USB |
| Operating Temperature ºC (ºF) | -20/+55 (-4/131) |
| Degree of Protection | IP67 |
| Overall Dimensions (without mount) | 7.37 x 2.46 x 2.33 in |
| Weight (without mount) | 0.91 lbs |
| Warranty | Limited 5 years |
