Sig Sauer

ECHO MV35 Thermal Monocular

  • Sale
  • $2,499.99

Sig Sauer ECHO MV35 Thermal Monocular

The new Sig Sauer ECHO MV is available in three models:

  • ECHO MV35 Thermal Monocular, 2-16x 35mm, 640x512, 50 Hz, ≤20 mK, 12.4° FOV;
  • ECHO MV50-LRF Thermal Monocular 3-24x 50mm, 640x512, 50 Hz, ≤20 mK, 8.7° FOV with integrated Laser Rangefinder; and
  • ECHO MV50-DV Thermal Monocular 1.5-24x 50mm, 640x512, 50 Hz, ≤20 mK, 17.1° - 8.7° FOV with Dual View (standard & wide view).

Leveraging years of experience creating the industry’s most innovative and rugged technologies, SIG SAUER’s new ECHO MV35 is a compact thermal monocular packed with industry-leading features and fully backed by SIG SAUER’s unrivaled Infinite Guarantee™.

The ECHO MV35 is powered by an LWIR 640x512 VGA, 12um 50Hz thermal core with <20mK sensitivity that allows you to clearly identify targets in total darkness with 8 selectable color palettes. Compatible with SIG SAUER’s BDX 2.0 Mobile App, the ECHO MV35 can capture both photo and video that can be viewed or shared in real-time via BDX 2.0.

Boasting one of the longest runtimes in the industry, the ECHO MV35 is capable of drawing power from an internal reserve cell, in addition to a removable 18500 lithium-ion battery. The device ships with (2) 18500 batteries to ensure that you have all the power you need for long nights afield.

Defy The Dark with the ECHO MV35, an unrivaled force in thermal imaging.

FEATURES:

  • 2-16x Digital Zoom
  • LWIR 640x512 VGA 12um 50Hz Thermal Core with <20mK sensitivity
  • Fully Backed by SIG SAUER’s Infinite Guarantee™
  • 8 Selectable Color Palettes
  • Record Photo and Video (With Audio)
  • BDX 2.0 Connectivity
  • 10-Hour Runtime
  • Includes (2) 18500 Rechargeable Lithium-Ion Batteries

Sig Sauer Electro-Optics Technology:

Infinite Guarantee - SIG SAUER Electro-Optics are guaranteed forever. It's an unlimited lifetime guarantee.
Ballistic Data Exchange 2.0 - Ballistic Data Exchange is a rangefinder and riflescope system that uses your ballistics, environmental conditions and Bluetooth to illuminate the exact holdover dot. BDX 2.0 is the Software Update that includes a new easy mode for quick BDX setup out of the box, including: BDX kits come paired and bonded. BDX Quickbond™ system gives users the ability to bond two BDX enabled devices without the smartphone app. BDX equipped KILO™ rangefinders preloaded with ballistic groups for centerfire rifles, muzzleloaders and crossbows. 100% compatible with BDX smartphone app to access the advanced BDX features in configuration options.
LightWave DSP™ - Lightwave DSP (Digital Signal Processing) engine leverages HyperScan– an advanced power management technique that provides the fastest refresh rate in scan mode (4 times per second) even at distances over a mile. Our DSP engine uses the latest generation Field Programmable Gate Array (FPGA) running sophisticated signal processing algorithms to reduce false positives while finding weak or distant targets.
Motac™ -Activated through motion sensing technology, MOTAC immediately powers up illumination when it senses motion and powers down when it does not in order to extend battery life.
Included in the box:
  • ECHO MV Thermal Monocular
  • Lens Cover
  • (2) 18650 Lithium-ion Rechargeable Batteries
  • USB-C to USB-C Data Cable
  • USB-C Split Charging Cable
  • Optic Multi-tool
  • Lens Cleaning Pen
  • Quick Reference Instructions
  • Hard Plastic Case

ITAR Control Statement

This product is subject to the International Traffic in Arms Regulations (ITAR). You many not export, re-export, resell, transfer or otherwise dispose of this product to any other country without first obtaining approval from the U.S. Department of State, Directorate of Defense Trade in accordance with the ITAR, Title 22, and Code of Federal Regulations Part 120-130. Diversion contrary to U.S. law is prohibited.
  • LWIR 640x512 VGA 12µm 50Hz thermal core with ≤20mK sensitivity.
  • Record still photos and video with audio.
  • BDX 2.0 enabled, including Applied Ballistics Ultralight with complete AB bullet
    database, full on-board environmental sensor suite, and live video streaming.
  • 8 selectable color palettes.
  • Rechargeable and removable 18650 lithium-ion batteries with 10-hour runtime on a single charge.
  • Configure settings and download media with the BDX App.
  • Record photos and videos to internal 32GB solid-state storage. Capture every thrilling moment in crisp detail, no matter where your adventure takes you.
  • Ships with (2) 18650 batteries, USB-C cable, flip back lens covers, removable eyepiece, and hard plastic case.
  • SIG SAUER® Infinite Guarantee™.
 Specifications MV35
Magnification 2-16x
Focal Length 35mm
Resolution 640 x 512
Pixel Pitch 12 µm
Thermal Sensitivity (NETD) ≤ 20mK
Frame Rate 50 Hz
Angular FOV 12.4°
Display Type OLED
Display Resolution 1024 x 768
Color Palettes 8
Reticles N/A
BDX Enabled Yes
Ballistic Profiles (BDX App) 25
Video/Audio Recording Yes
Image Capture Yes
Media Storage 32 GB
Communications Wi-Fi / Bluetooth
Laser Rangefinder No
Max. Measuring Range N/A
Laser Safety Class N/A
Mount Type None
Length 7.0"
Overall Diameter 2.4"
Weight (w/o battery) 19.0 oz
Battery (2) 18650
Runtime 10 hours
Carry Case included Yes
Waterproof rating IP67
Warranty Lifetime
